STRATOVIN

Digital Print Media
by StratoJet

Request Information

Product Details

StratoJet’s Simple Adhesive Solvent and UV-curable Gloss Vinyl is priced like an economy vinyl, but provides the longer-term durability, photographic image quality, and easy handling of an intermediate-priced product. It is suitable for so many popular applications that you don’t need to maintain a costly inventory of different products for various job requirements, and compete against
This multi-purpose vinyl makes it easy to handle during printing and installation, and its permanent adhesive works with all standard sign substrates. It produces photographic image quality on graphics that will last three to five years outdoors.
The glossy finish of this vinyl produces graphics with more vibrant colors and sharper details.
StratoJet’s Simple Adhesive Vinyl Stratovin works well on a wide range of printers that use solvent, low-solvent, and UV-curable, latex and clean inks.
Using a StratoJet Printer? Get custom color profiles to ensure perfect colors for both outdoor and indoor applications.
Other Two Products available: Poster Paper, and Matte Lamination films (For details email – info@stratojetusa.com) DOWNLOAD BROCHURE

Technical Specifications

Product Type Inkjet Printable Media
Thickness 5 mil
Applications - Media Featured
Outdoor Signage
Billboards
Finish Gloss
Ink Type Clean
Latex
UV Curable
Eco-Solvent / Solvent
Media Type Vinyl: Calendered
Adhesive Backed
Core Size 3 in
Width 36 in
Length 150 ft
Units 1 Roll
Double Sided No
Lifetime Warranty No
<Properties Description
Material Calendared PVC
Gauge 4.5 mil
Gauge of Adhesive 1mil permanent solvent-based acrylic adhesive
Release Liner 5.5 mil double PE liner
Total Gauge 11 mils
White Point 84 ± 5 (CIE)
L*a*b* Values L* = 93.51; a*= -0.3; b*= -1.73
Opacity 76%
Gloss Level at 60° 58 ± 5
180° Peel Adhesion to Stainless Steel 1.2 kg/25 mm
Printer/Ink Compatibility Compatible all inkjet printers using eco solvent, solvent, latex and UV-curable ink.
Software Settings Printer settings will vary between printer manufacturers. Recommended heater settings: Pre-heat 40° C, platen 38-42° C and post-heat 50° C have been found as a good place to start.
Color Matching For the best and most consistent results, a profile should be created using an external color calibrator in conjunction with your RIP and color matching software.
Finishing/Post Processing Pressure-sensitive vinyl laminates can be applied to increase the fade and abrasion resistance of the image. Before applying the laminate, allow the image to dry for 24 hours. Residual solvent trapped beneath a laminate as a result of insufficient dry time can cause color shifts.
Light Fastness The fading time of inkjet ink is a direct result of the inks that you choose to use and the environment where the print is displayed. Contact the ink manufacturer for light-fastness data.
Durability 3-5 years outdoors
Optimal Print Environment 70° F (21° C), 50% R.H
Optimal Service Environment For printing: 60° - 80° F, 50% Relative Humidity.
Service Temp. Range -40° - 176° F (-40° C to 80° C).
Minimum Application Temp. 40° F
Shipping Instructions Always roll graphics with the thinnest material facing out. When both materials are the same thickness, always roll them in the same way every time. StratoJet recommends rolling the graphic with a minimum 12 inch diameter.
Ideal Storage Conditions 70° F (21° C), 50% R.H. (a controlled environment is recommended); store vertically in original packaging.
Shelf Life 1 year from the StratoJet ship date when stored in proper conditions.
Health & Safety WARNING: This product contains a chemical known to the State of California to cause cancer.
